Specifications:
Brand:
SARO
Model:
SPA
Over Guideways:
31 1/2" (800 mm)
Over Cross Slide:
19 5/8" (490 mm)
In Gap:
41 3/4" (1060 mm)
Length turned in Gap:
12" (300 mm)
Distance between Centres:
196 7/8" (5000 mm)
MAXIMUM OF WORKPIECE
Between Centres without Rest: 7700 Lb (3500 kg)
Between Centres with Rest: 9900 Lb
(4500 kg)
In Face Plate:
1760 Lb (800 kg)
Main Spindle Nose:
CAMLOCK D1-11
Main Spindle Bore:
4 1/8" (105 mm)
Main Spindle Bore Taper:
METRIC 10
Speed Range:
8-1250 RPM
Number of Speeds:
23
FEEDS AND THREADS
Longitudinal:
44 0,056 - 10 mm/rev
Cross Feeds:
44 0,0186 - 3,33
Metric:
43 1 - 176
Whitworth:
44 80 - 1/4
Module:
39 0,5 - 80
Diametral:
39 160 - 1
Inch:
46 1/32 - 10
CROSS SLIDE AND TOOLHOLDER
Cross Slide:
15 3/4" (400 mm)
Toolholder Slide Stroke: 6 7/8" (175 mm)
TAILSTOCK
Diameter of the Quill: 4 1/8" (105 mm)
Cone of the Quill:
MORSE 6
Travel of the Quill:
12" (300 mm)
DRIVING
Main Motor:
30 HP (22 kW)
Rapid Feed Motor:
0,75 HP (0,55 kW)
Cooling Pump Motor: 0,12 HP (90 W)
OVERALL DIMENSIONS
LENGTH:
23'9" (7240 mm)
WIDTH:
60" (1510 mm)
HEIGHT:
65" (1650 mm)
WEIGHT:
18040 Lbs (8,2 t)
Lathe Color: Standard color Grey & Blue
Electrical Supply: 575V/3ph/60Hz, CSA Approved
Included accesories:
Price (FOB Canada, Montreal):
. . . . . . . . . . . . . . . . . . . $86,250.00 CAD
or $53,906.00 USD
Accesories (extra):
|
|
|
|
